• Rating：12mA 24VDC
• Contact Resistance：50mΩ Max.(Initial)
• Insulation Resistance：100MΩ min(at 500VDC)
• Dielectric Strength：AC 250V 50/60Hz FOR 1 min
• Operating Force：170±100gf(Momentary)
• Electric Life：1,000,000 cycles Min
• Ambient Temperature：-10℃ ~ +60℃
• Total Travel：2.5mm±0.5mm
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electric Life | Ambient Temperature | Total Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R2995-O | 12mA 24VDC | 50mΩ Max.(Initial) | 100MΩ min(at 500VDC) | AC 250V 50/60Hz FOR 1 min | 170±100gf(Momentary) | 1,000,000 cycles Min | -10℃ ~ +60℃ | 2.5mm±0.5mm | 暫無 |
| R2995-1L | 12mA 24VDC | 50mΩ Max.(Initial) | 100MΩ min(at 500VDC) | AC 250V 50/60Hz FOR 1 min | 170±100gf(Momentary) | 1,000,000 cycles Min | -10℃ ~ +60℃ | 2.5mm±0.5mm | 暫無 |
| R2995-2L | 12mA 24VDC | 50mΩ Max.(Initial) | 100MΩ min(at 500VDC) | AC 250V 50/60Hz FOR 1 min | 170±100gf(Momentary) | 1,000,000 cycles Min | -10℃ ~ +60℃ | 2.5mm±0.5mm | 暫無 |
