• Rating：100mA max,42 VAC/DC
• Contact Resistance：100mΩ max.(initial)
• Insulation Resistance：100MΩ min
• Dielectric Strength：1,000 VAC
• Force：3N±0.75N
• Travel：0.6±0.2mm
• Operating Temperature Range：-25℃ ~+ 70℃
• Mechanical Life：1,000,000 cycles
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Force | Travel | Operating Temperature | Mechanical Life | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R2092-5A0 | 100mA max,42 VAC/DC | 100mΩ max.(initial) | 100MΩ min | 1,000 VAC | 3N±0.75N | 0.6±0.2mm | -25℃ ~+ 70℃ | 1,000,000 cycles | 暫無 |
| R2092-5D0 | 100mA max,42 VAC/DC | 100mΩ max.(initial) | 100MΩ min | 1,000 VAC | 3N±0.75N | 0.6±0.2mm | -25℃ ~+ 70℃ | 1,000,000 cycles | 暫無 |
| R2092-5B | 100mA max,42 VAC/DC | 100mΩ max.(initial) | 100MΩ min | 1,000 VAC | 3N±0.75N | 0.6±0.2mm | -25℃ ~+ 70℃ | 1,000,000 cycles | 暫無 |
| R2092-5C | 100mA max,42 VAC/DC | 100mΩ max.(initial) | 100MΩ min | 1,000 VAC | 3N±0.75N | 0.6±0.2mm | -25℃ ~+ 70℃ | 1,000,000 cycles | 暫無 |
| R2092-9A | 100mA max,42 VAC/DC | 100mΩ max.(initial) | 100MΩ min | 1,000 VAC | 3N±0.75N | 0.6±0.2mm | -25℃ ~+ 70℃ | 1,000,000 cycles | 暫無 |
| R2092-9B | 100mA max,42 VAC/DC | 100mΩ max.(initial) | 100MΩ min | 1,000 VAC | 3N±0.75N | 0.6±0.2mm | -25℃ ~+ 70℃ | 1,000,000 cycles | 暫無 |
| R2092-9C | 100mA max,42 VAC/DC | 100mΩ max.(initial) | 100MΩ min | 1,000 VAC | 3N±0.75N | 0.6±0.2mm | -25℃ ~+ 70℃ | 1,000,000 cycles | 暫無 |
