• Rating：12VDC 50mA
• Contact Resistance：100mΩ Max
• Insulation Resistance：100MΩ min(250VDC)
• Dielectric Strength：250VAC 50/60Hz FOR 1 min
• Operating Force：160±50g/250±80g
• Electric Life：100,000 cycles
• Operating Temperature Range：-20℃ ~ + 70℃
• Travel：0.25±0.1 mm
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electric Life | Operating Temperature Range | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R590A-1L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-1 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-2L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-2 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-3L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-3 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-4 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-3ML(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-3M | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590A-1G | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
