• Rating：12VDC 50mA
• Contact Resistance：100mΩ Max
• Insulation Resistance：100MΩ min(250VDC)
• Dielectric Strength：250VAC 50/60Hz FOR 1 min
• Operating Force：160±50g/250±80g
• Electric Life：100,000 cycles
• Operating Temperature Range：-20℃ ~ + 70℃
• Travel：0.25±0.1 mm
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electric Life | Operating Temperature Range | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R590B-101L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-101 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-102L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-102 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-111L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-111 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-112L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-112 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-203L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-203 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-204L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-204 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-223L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-223 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-224L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-224 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-253L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-253 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-254L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-254 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1810L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1810 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1814L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1814 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-141L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-141 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-142L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-142 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-140L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-140 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-108L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-108 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1013L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1013 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-178L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-178 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1713L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1713 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1010L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1010 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1014L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-1014 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-107L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-107 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-3011L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-3011 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-3311L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-3311 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-3012L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-3012 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-3612L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-3612 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-305L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-305 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-2RL(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-2R | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-203RL(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-203R | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-101RL(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-101R | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-107RL(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-107R | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-142RL(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-142R | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R590B-04□L-□□ | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g/250±80g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
